SYVSG-B500K40G Portable Vector Signal Generator

TECHNICAL DATA

Technical specifications

Specifications correspond to the product catalogue. Contact our technical team for configuration and operating conditions.

SYVSG-B500K40G Technical specifications
Parameter	Specification / typical value
Functional Specifications
I/Q data loading	Supported
Built-in self-test	Supported
Remote control	Supported
Graphical user interface	Supported
Logging	Supported
Sync output & external pulse modulation	Supported
Multiple modulations: AM, FM, PM, CW, ASK, PSK, FSK, QAM, etc.	Supported
Touchscreen & key control	Supported
AC adapter / battery powered	Supported
Technical Specifications
Output Frequency	500kHz～40GHz
Output Frequency Accuracy	≤1ppm
Instantaneous Bandwidth	≤600MHz
Output Power	-120dBm～+10dBm（500kHz～18GHz）；-110dBm～ +5dBm（18GHz～40GHz）
Min. Output Power Step	0.1dB
Power Accuracy	±1.5dB (output power ≥-60dBm); ±0.5dB (output power ≥-40dBm)
Sweep Mode	Step sweep, list sweep, etc.
Output VSWR	≤1.8
Harmonics	≤-40dBc (output power -20dBm)
Spurious	≤-40dBc
Phase Noise	≤-105dBc/Hz @ 10kHz (10GHz output)
General Specifications
Dimensions (L×W×H)	320 mm × 240 mm × 60 mm (excluding corner guards and handle)
Weight	≤5 kg (including battery)
Battery Life	≥2h
Operating Temperature	-10℃～+50℃
Storage Temperature	-20℃～+70℃

Specifications are subject to change without notice. Contact our technical team for full conditions, interface definitions, and ordering information.

Take anti-static precautions and ensure device ports are clean before use.
Use a torque wrench to tighten coupling nuts where applicable.
Check connector pin depth before calibration to avoid damage to calibration devices.
